{"Contact Classification":"12Signal","Strain Relief":"No","Number of Terminals":"12","Family":"M83723","Voltage Rating":"850VDC/600VAC","Gender":"PL","Body Orientation":"Straight","Contact Gender":"SKT","Mounting Style":"Cable","Number of Ports":"1(Port)","Rad Hardened":"No","Product Diameter (mm)":"41.28(mm)","Termination Method":"Crimp","Operating Temp Range":"-65C to 175C","Shell Size / Insert Arrangement":"22-12","Number of Contacts":"12(POS)","Type":"Circular","Product Length (mm)":"36.07(mm)","Contact...

{"Contact Classification":"12Signal","Type":"Circular","Product Height (mm)":"Not Required(mm)","Termination Method":"Crimp","Shell Size / Insert Arrangement":"22-12","Strain Relief":"No","Shell Plating":"Cadmium Over Nickel","Voltage Rating":"850VDC/600VAC","Gender":"PL","Body Orientation":"Straight","Contact Gender":"SKT","Number of Ports":"1(Port)","Operating Temp Range":"-65C to 175C","Product Diameter (mm)":"41.28(mm)","Family":"M83723","Number of Terminals":"12","Mounting Style":"Cable","Rad Hardened"...

{"Status":"ACTIVE","Body/Shell Style":"PLUG","MIL Conformance":"Yes","Total Number of Contacts":"12","Option":"GENERAL PURPOSE","Mounting Type":"CABLE","Contact Finish - Mating":"NOT SPECIFIED","Shell Finish":"OLIVE DRAB CADMIUM PLATED","Backshell Type":"SOLID","Environmental Characteristics":"CORROSION/ENVIRONMENT/FLUID/IMMERSION RESISTANT","Contact Finish - Termination":"NOT SPECIFIED","Contact Gender":"FEMALE","Coupling Type":"BAYONET","Manufacturer Series":"M83723/75W","Mating Information":"MULTIPLE MAT...

{"Category":"Connectors, Interconnects","Current Rating":"23A","Voltage - Rated":"600VAC","Operating Temperature":"-65\u00b0C ~ 200\u00b0C","Shell Size, MIL":"-","Contact Finish Thickness":"-","Number of Positions":"12","Mating Products":"AM83723/72W22126-ND - CONN RCPT 12POS WALL MT W/PINS","Datasheets":"MIL-C-83723 Series III Catalog","Standard Package":"1","Family":"Circular Connectors","Shell Size - Insert":"22-12","Connector Type":"Plug, Female Sockets","Contact Finish":"Gold","Associated Product":"APC...

{"Status":"ACTIVE","Body/Shell Style":"PLUG","MIL Conformance":"Yes","Total Number of Contacts":"12","Option":"GENERAL PURPOSE","Mounting Type":"CABLE","Contact Finish - Mating":"NOT SPECIFIED","Shell Finish":"CADMIUM PLATED","Backshell Type":"SOLID","Environmental Characteristics":"CORROSION RESISTANT; ENVIRONMENT RESISTANT; FLUID RESISTANT","Contact Finish - Termination":"NOT SPECIFIED","Contact Gender":"FEMALE","Coupling Type":"BAYONET","Manufacturer Series":"M83723","Mating Information":"MULTIPLE MATING...

{"Connector Shell Size:":"22","Connector Mounting:":"Cable","Contact Termination:":"Crimp","Contact Material:":"Copper Alloy","Contact Plating:":"Gold","Contact Gender:":"Socket","Product Range:":"MIL-C-83723 Series III","Gender:":"Plug","No. of Contacts:":"12","Connector Type:":"Circular Military","Connector Body Material:":"Aluminium","Insert Arrangement:":"22-12","Contact Termination Type:":"Crimp","SVHC:":"To Be Advised"}...

{"Connector Shell Size:":"22","Connector Mounting:":"Cable","Insert Arrangement:":"22-12","Product Range:":"MIL-C-83723 Series III","Gender:":"Plug","No. of Positions:":"12","Connector Type:":"Circular Military","Connector Body Material:":"Aluminium","SVHC:":"To Be Advised","Contact Gender:":"Socket"}...

{"Contact Classification":"12Signal","Type":"Circular","Current Rating (Max)":"23(A)","Product Height (mm)":"Not Required(mm)","Contact Plating":"Gold","Termination Method":"Crimp","Shell Size / Insert Arrangement":"22-12","Strain Relief":"No","Shell Plating":"Cadmium Over Nickel","Gender":"PL","Body Orientation":"Straight","Contact Gender":"SKT","Number of Ports":"1(Port)","Operating Temp Range":"-55C to 175C","Product Diameter (mm)":"42.06(mm)","Family":"M83723","Number of Terminals":"12","Mounting Style"...

{"Category":"Connectors, Interconnects","Current Rating":"23A","Voltage - Rated":"-","Operating Temperature":"-55\u00b0C ~ 200\u00b0C","Shell Size, MIL":"-","Contact Finish Thickness":"50\u00b5in (1.27\u00b5m)","Number of Positions":"12","Datasheets":"MIL-C-83723 Series, 1, 3","Standard Package":"1","Family":"Circular Connectors","Shell Size - Insert":"22-12","Connector Type":"Plug, Female Sockets","Contact Finish":"Gold","Fastening Type":"Bayonet Lock","Termination":"Crimp","Features":"-","Ingress Protecti...

{"Category":"Connectors, Interconnects","Note":"Contacts Not Provided","Mounting Type":"Free Hanging (In-Line)","Shell Size, MIL":"-","Number of Positions":"12","Mating Products":"DM83723/72W22126-LC-ND - CONN HSG RCPT FLANGE 12POS PIN DM83723/74W22126-LC-ND - CONN HSG RCPT JAM NUT 12POS PIN DM83723/72W22126-ND - CONN RCPT 12POS FLANGE W/PINS DM83723/74W22126-ND - CONN RCPT 12POS JAM NUT W/PINS","Datasheets":"MIL-C-83723 Series, 1, 3","Standard Package":"1","Contact Size":"12","Shell Size - Insert":"22-12",...
