{"Category":"Discrete Semiconductor Products","Packaging":"Tape & Reel (TR)","Online Catalog":"Schottky Diode","Current - Reverse Leakage @ Vr":"2mA @ 20V","Mounting Type":"Surface Mount","Product Photos":"DO-214AB","Standard Package":"3,000","Series":"-","Capacitance @ Vr, F":"-","Voltage - Forward (Vf) (Max) @ If":"500mV @ 3A","Supplier Device Package":"SMC","Reverse Recovery Time (trr)":"-","Datasheets":"MBRS320 DO214AB Pkg Drawing","Family":"Diodes, Rectifiers - Single","Operating Temperature - Junction...

{"Rectifier Type":"Schottky Diode","Peak Rep Rev Volt":"20(V)","Peak Non-Repetitive Surge Current":"80(A)","Operating Temperature Classification":"Military","Mounting":"Surface Mount","Forward Current":"4000(mA)","Forward Voltage":"0.5(V)","Packaging":"Tape and Reel","Rev Curr":"2000(uA)","Rad Hardened":"No","Package Type":"SMC","Peak Forward Voltage":"0.5(V)","Maximum Forward Current":"4000(mA)","Operating Temp Range":"-65C to 125C","Peak Reverse Current":"2000(uA)","Configuration":"Single","Pin Count":"2"...

{"Status":"EOL/LIFEBUY","Package Body Material":"PLASTIC/EPOXY","Mfr Package Description":"SMC, SIMILAR TO DO-214AB, 2 PIN","Terminal Form":"C BEND","Package Style":"SMALL OUTLINE","Rep Pk Reverse Voltage-Max":"20 V","Number of Phases":"1","Diode Element Material":"SILICON","Average Forward Current-Max":"3 A","Application":"GENERAL PURPOSE","Number of Elements":"1","Non-rep Pk Forward Current-Max":"820 A","Terminal Position":"DUAL","Diode Type":"RECTIFIER DIODE","Package Shape":"RECTANGULAR","Configuration"...
